120 W Multi-Zone Mixer Amplifier with Phantom Power Control

MXA 3000 SeriesIntegrated mixing amplifier – 120Wrms – Output for selected zones – 230V/115V
PRODUCT DESCRIPTION·2 balanced/unbalanced microphone inputs with phantom power supply·Microphone input or microphone stations of the MBT 1000 range·2 MIC/PH/LINE inputs with specific selector switch·2 auxiliary inputs for sound sources (TAPE/CD)
·Telephone/emergency audio input for priority calls with adjustable threshold and sensitivity·Front-panel adjustment of the level of each microphone and auxiliary input·Front-panel control of overall volume and of treble and bass tones·Provisions for inserting via the front panel a USB/SD CARD module ( )·Constant voltage (50/70/100 V) or 8 impedance loudspeaker line output·3 output lines for zones·Balanced line output for connection to other amplifiers·Output/input for connection to audio processors·LED-type Vu meter for clear and immediate reading of power emitted·Micro-switches for setting operating modes·Includable/excludable speech filters on all microphone inputs·Contacts for activating input precedence and override·”Music On Hold” output with output level control (output of the selected auxiliary signal)·Alerting signal (chime) with level control·Front-panel keys for selecting music listening zonesSelectable mains power supply – 230/115 VAC or 24 VDC
